seuic東集X5高性能工業視覺讀碼器參數:
照明光源
白色或紅色LED(特殊機型可定制藍色LED)
支持碼制
1D:Code128、GS1 128、Code39、Code93、codabar、交叉25碼、EAN/UPC
2D:QR、DataMatrix(ECC200)、PDF417、Micro PDF417
控制輸出最大負載電流
1 個輸出 :50 mA 或更低 共計 3個輸出 :100 mA 或更低
Ethernet支持的協議
TCP/UDP TCP Client,TCP Server,FTP,Profinet,MELSEC, Ethernet/IP,ModBusTcp(poll/slave),Fins
串行通信傳輸速度
115200/57600/38400/19200/9600 bps
USB通信標準
符合 USB 2.0 Full Speed
尺寸
61.2mm x 48.7mm x 45.55mm
